Power Rating：500W*2
Frequency Response：20Hz-20KHz，±0.5dB
Sensitivity Of Input：0.77V
Input lmpedance:20kΩBalanced.10kΩ/un-Balanced
S/N Ratio: ≥95dB
THD：≤0.03%
Channel separation degree：>70dB
Damping Factor: >240
Slew rate：15V/uS
Mains Power supply：AC:220-230V 50Hz/60Hz
Weight：12.5Kg
W*H*D：482mm*304mm*88mm

Power Rating：750W*2
Frequency Response：20Hz-20KHz，±1.5dB
Sensitivity Of Input：0.77V
Input lmpedance:20kΩBalanced.10kΩ/un-Balanced
S/N Ratio: ≥100dB
THD：≤0.05%
Channel separation degree：>65dB
Damping Factor: >230
Slew rate：15V/uS
Mains Power supply：AC:220-230V 50Hz/60Hz
Weight：12.6Kg
W*H*D：482mm*362mm*88mm

Power Rating：900W*2
Frequency Response：20Hz-20KHz，±1.5dB
Sensitivity Of Input：0.77V
Input lmpedance:20kΩBalanced.10kΩ/un-Balanced
S/N Ratio: ≥100dB
THD：≤0.05%
Channel separation degree：>65dB
Damping Factor: >230
Slew rate：15V/uS
Mains Power supply：AC:220-230V 50Hz/60Hz
Weight：14.1Kg
W*H*D：482mm*362mm*88mm

Power Rating：1100W*2
Frequency Response：20Hz-20KHz，±1.5dB
Sensitivity Of Input：0.77V
Input lmpedance:20kΩBalanced.10kΩ/un-Balanced
S/N Ratio: ≥100dB
THD：≤0.05%
Channel separation degree：>65dB
Damping Factor: >230
Slew rate：15V/uS
Mains Power supply：AC:220-230V 50Hz/60Hz
Weight：16.3Kg
W*H*D：482mm*362mm*88mm

Output power: 8 Ω/ 2400W × 2, 4 Ω/ 3500W × 2；

Frequency response: 20Hz ~ 20kHz - 3dB ~ + 0.5dB;

Power supply: 220 V (50 Hz ~ 60 Hz);

Damping coefficient: > 300;

Volume: H 88mm x w 482mm × 394.7mm

Net weight: 13.5kg

Output power: 8 Ω/ 950W × 4, 4 Ω/ 1400W × 4；

Frequency response: 20Hz ~ 20kHz - 3dB ~ + 0.5dB;

Power supply: 220 V (50 Hz ~ 60 Hz);

Damping coefficient: > 300;

Volume: H 88mm x w 482mm × 394.7mm；

Net weight: 11.9kg

Output power: 8 Ω/ 1300W × 4, 4 Ω/ 1950W × 4；

Frequency response: 20Hz ~ 20kHz - 3dB ~ + 0.5dB;

Power supply: 220 V (50 Hz ~ 60 Hz);

Damping coefficient: > 300;

Volume: H 88mm x w 482mm × 394.7mm；

Net weight: 12.1kg

Output power: 8 Ω/ 1300W × 2, 4 Ω/ 1900W × 2；

Frequency response: 20Hz ~ 20kHz - 0.5dB;

Power supply: 220 V (50 Hz ~ 60 Hz);

Damping coefficient: > 240;

Volume: height 132mm x width 482mm × 530mm；

Net weight: 30kg

Output power: 8 Ω/ 1800W × 2, 4 Ω/ 2600W × 2；

Frequency response: 20Hz ~ 20kHz - 0.5dB;

Power supply: 220 V (50 Hz ~ 60 Hz);

Damping coefficient: > 240;

Volume: height 132mm x width 482mm × 530mm；

Net weight: 35kg

Rated power (THD = 1% continuous sinusoidal 1kHz typical value): 8 Ω / stereo 2x2000w

4 Ω / stereo 2x3400w 2 Ω / stereo 2x5800w 16 Ω / bridge 1x4000w

8 Ω / bridge 1x6800w 4 Ω / bridge 1x11560w

RMS output voltage (THD = 1% 1kHz): 126.5v

Input sensitivity (rated output power, 1kHz): 41db, 38dB, 35dB, 32dB can be selected

Thd + N: typical value: 0.01% (10% rated output power, 1kHz, 8 Ω)

Crosstalk suppression: ≥ 90dB (below rated power, 20Hz kHz, 8 Ω)

Frequency response: typical value: + 0dB, - 0.5dB (10% rated output power, 20Hz-20KHz, 8 Ω)

Input impedance: 20K Ω (balanced), 10K Ω (unbalanced)

Damping coefficient: typical value: 5000 (20HZ-200HZ, 8 Ω)

SNR: ≥ 105dB (A-weighted, 20Hz-20KHz, 8 Ω)

Power requirements: 90 ∽ 260vac, 50 / 60Hz

Protection functions: power supply undervoltage protection, power amplifier output DC protection, overheating protection, temperature power control, overload power control

Dimension (wxhxd): 483x45x370mm

Net weight: 9kg

Rated power: 8 Ω: 2 * 2450; 4Ω：2*4000W；



Bridging: 16 Ω: 4900W; 8Ω：8000W； RMS



Output voltage (THD = 1%, 1kHz); 138.6V；



Input sensitivity (rated output power, 1kHz):



Optional: 32dB, 35dB, 38dB, 41db; THD+N(10%



Rated output power (typical value): 0.03%;



Crosstalk suppression (lower than rated power, 20Hz ~ 1kHz, 8 Ω) ≥ 90dB;



Frequency response (10%)



Rated output power, 8 Ω, 20Hz ~ 20kHz): + 0dB, - 0.5dB;



Input impedance: 20K Ω (balanced), 10K Ω



(unbalanced); damping coefficient (8 Ω, 20Hz ~ 200Hz):



Typical value: 500;



Signal to noise ratio (A-weighted, 20Hz ~ 20kHz): ≥ 105dB;



Power requirements: 200 ~ 260vac, 50 / 60 Hz;



Protection functions: power supply undervoltage protection, power amplifier output DC protection, overheating protection, temperature power control, overload power control;



Size and net weight: 483 × forty-five × 370mm，9kg。

Rated power (THD = 1% continuous sinusoidal 1kHz typical value): 8 Ω / stereo 2x3000w

4 Ω / stereo 2x5100w 2 Ω / stereo 2x8670w 16 Ω / bridge 1x6000w

8 Ω / bridging 1x10200w 4 Ω / bridging 1x17340w

RMS output voltage (THD = 1% 1kHz): 154.9v

Input sensitivity (rated output power, 1kHz): 41db, 38dB, 35dB, 32dB can be selected

Thd + N: typical value: 0.01% (10% rated output power, 1kHz, 8 Ω)

Crosstalk suppression: ≥ 90dB (below rated power, 20Hz kHz, 8 Ω)

Frequency response: typical value: + 0dB, - 0.5dB (10% rated output power, 20Hz-20KHz, 8 Ω)

Input impedance: 20K Ω (balanced), 10K Ω (unbalanced)

Damping coefficient: typical value: 5000 (20HZ-200HZ, 8 Ω)

SNR: ≥ 105dB (A-weighted, 20Hz-20KHz, 8 Ω)

Power requirements: 90 ∽ 260vac, 50 / 60Hz

Protection functions: power supply undervoltage protection, power amplifier output DC protection, overheating protection, temperature power control, overload power control

Dimension (wxhxd): 483x45x465mm

Net weight: 13kg
